SectionCalc
Section Profile Calculation Software
SectionCalc® is groundbreaking software wizard that enables users to calculate all fourteen (14) vital section-properties of any profile in any DXF-compliant CAD application in less than one minute. Best pf all, SectionCalc is priced to justify on every engineer’s desktop.
How does SectionCalc work?
Calculating section properties with SectionCalc is easy as 1, 2, and 3.
- Save profile geometry of the section in CAD in DXF standard file format.
- Start SectionCalc and simply load the DXF file.
- See results in seconds
Following section properties are simultaneously calculated and displayed in SectionCalc in one step.
- Area
- Perimeter
- Centroid location (x and y co-ordinates)
- Moments of Inertia (Ixx, Iyy)
- Product of Inertia
- Polar Moments of Inertia
- Distance of neutral axis from extremes (Cx and Cy)
- Radius of gyration (kx and ky)
- Section Modulus (Sx and Sy)
Results can be saved in CSV standard format for report generation.
SectionCalc Examples
SectionCalc key Benefits
- Accepts any standard, custom, or built-up section
- No manual data entry – works directly with CAD geometry
- Automatically detects holes, islands, and nested regions
- Automatically aligns results to centroid of section
- Automatically sets results to CAD system units (metric, inches, feet)
- Answers with up to 9 decimal place precision (user selectable)
- Save results in CSV file format (readable by Excel)
- Start using in less than five minutes
SectionCalc can be used on any computer running Vista, XP, Windows 7, Windows 8, or Windows 10.
SectionCalc – get CAD profile properties in minutes!
